| Frequency Ranges |
VHF： 66-88 / 136-174 MHz
UHF：400-480 MHz |
| Openating Mode |
Co-Channel or Dis-Channel Simplex |
| Output Power |
1W / 4W / 8W |
| Memory Channels |
16 |
| Voltage |
7.4 VDC |
| Working Temperature |
-30℃ ~ +60℃ |
| Antenna Impedance |
50Ω |
|
| Modulation Type |
FM(F3E) |
| Max. Frequency Deviation |
≤5 KHz |
| Frequency Stability |
±5 PPM |
| Sensitivity (12dB SINAD) |
≤0.2 µV |
| Audio Output power |
≥500 mW |
| Spurious Radiation |
≤-60 dB |
| Waterproof |
IP67 |
| Weight |
320 G |
| Dimension |
132 x 62 x 37 (MM) |
|
