| Frequency Ranges |
VHF： 66-88 / 136-174 / 245-250 / 216-280 MHz
UHF：350-390 / 400-480 / 420-520 MHz |
| Channel Spacing |
Wide : 25KHz , Narrow : 12.5KHz |
| Output Power |
VHF=5W / 1W , UHF=4W / 1W |
| Memory Channels |
16 |
| Voltage |
7.4 VDC |
| Working Temperature |
-30℃ ~ +60℃ |
| Antenna Impedance |
50 Ω |
| Dimension |
57 x 36 x 116 (MM) |
|
| Audio Distortion |
≤5% |
| Modulation Type |
FM(F3E) |
| Max. Frequency Deviation |
≤5 KHz |
| Adjacent Channel Selection |
≥65 dB |
| Frequency Stability |
±2.5 PPM |
| Sensitivity (12dB SINAD) |
≤0.2 µV |
| Audio Output power |
≥500 mW |
| Spurious Radiation |
≤-60 dB |
| Waterproof |
IP55 |
| Weight |
210 G |
|
