| General |
| Frequency Range , TX |
118-136(AM) & 136-174 & 400-480 MHz |
| Frequency Range , RX |
76-108(FM) & 118-136(Air Ground , AM) MHz
136-174(FM) & 320-400(FM) MHz
400-480(FM) MHz |
| Frequency Step |
2.5 / 5.0 / 6.25 / 8.33 / 10 / 12.5 / 25 / 50 / 100 KHz |
| Channel Number |
999 |
| Work Mode |
F2D / F3E |
| Operating Temperature |
-20℃ ~ +40℃ |
| Voltage |
7.4VDC |
| Antenna Impedance |
50Ω |
|
| Receiver |
| |
Wide |
Narrow |
| Adjacent Channel Selectivity |
≤70dB |
≤60dB |
| Inter Modulation |
≤65dB |
≤60dB |
| Spurious Response |
≤70dB |
≤70dB |
| Audio Response |
+1 ~ -3dB (0.3~3KHz) |
+1 ~ -3dB (0.3~3KHz) |
| Signal to Noise Ratio |
≥45dB |
≥40dB |
| Audio Distortion |
≤5% |
| Audio Power |
≤500mW |
| Sensitivity |
118-136MHz(AM) -106.0dbm SN 13dB
136-174MHz -119.0dbm SINAD 13dB
400-480MHz -119.0dbm SINAD 13dB |
|
