| General |
| Frequency Range |
Customized to Dual Band ro Single Band
DB : 136-174 & 400-520 MHz
SB : 136-174 or 400-470 or 400-520 MHz |
| Channel Number |
3072 |
| Channel Spacing |
Digital : 12.5 KHz
Analog : 12.5 / 25.0 KHz |
| Operating Temperature |
-20℃ ～ +40℃ |
| Antenna Resistance |
50Ω |
| Working Voltage |
7.4VDC |
| Waterproof |
IP65 |
| Weight |
490G |
| Dimension |
124.5 x 61.5 x 33.8 MM |
|
| Transmitter |
| FM Modulation |
12.5KHz : 11KOF3E , 25KHz : 16KOF3E |
| 4FSK Digit Modulation |
12.5KHz(Data Only) : 7K60FXD
12.5KHz(Data+Voice) : 7K60EXE |
| Adjancent Channel Power |
≤-60dB |
| Frequency Stability |
±1 PPM |
| Audio Distortion |
≤5% |
| Vocoder Type |
AMBE+2TM |
| Audio Response |
+1dB~-3dB |
| Digital Protocol |
ETSI-TS102 , 361-1 , 361-2 , 361-3 |
| Bit Error Ratio |
≤5% |
| Modulation Limit |
±2.5KHz@12.5KHz |
| Output Power |
Standard = 5W , Max = 10W ( Optional ) |
|
