| Intergration |
| Frequency Range |
136-174MHz , 400-520MHz |
| Channel Number |
3072 |
| Operating Temperature |
-20℃～+40℃ |
| Antenna Resistance |
50Ω |
| Working Voltage |
7.4 VDC |
| Weight |
300 g |
| Size |
64 x 41 x 130 (mm) |
|
| Receiver |
| Analog Receive Sensitivity |
0.25µV@12dB SINAD |
| Digital Receive Sensitivity |
0.25µV(BER:5%) |
| Adjacent Channel Selectivity |
≤60dB@12.5KHz |
| Audio Response |
+1dB~-3dB |
| Audio Distortion |
≤5% |
| Audio Power |
1W |
| Inter Modulation |
≥65dB |
|
| |
|
| Transmitter |
| FM Modulation |
12.5KHz : 11KOF3E , 25KHz : 16KOF3E |
| 4FSK Digit Modulation |
12.5KHz(Data Only) : 7K60FXD
12.5KHz(Data+Voice) : 7K60FXE |
| Adjancent Channel Power |
≤-60dB |
| Frequency Stability |
±1 PPM |
| Audio Distortion |
≤5% |
| Vocoder Type |
AMBE+2TM |
| Audio Response |
+1dB~-3dB |
| Digital Protocol |
ETSI-TS102 , 361-1 , 361-2 , 361-3 |
| Bit Error Ratio |
≤5% |
| Modulation Limit |
±2.5KHz@12.5KHz |
| Output Power |
UHF ( H : 4W , L : 1W) , VHF ( H : 5W , L : 1W) |
|
|
|
